Switch-Pros

Switch-Pros® RCR-FORCE® 12 Switch Panel Power System

Switch-Pros® RCR-FORCE® 12 Switch Panel Power System

Regular price $1,078.00 USD
Regular price Sale price $1,078.00 USD
Sale Sold out
Add a Mount
  • 12 user-programmable switches
  • RCR-TOUCH™ switch cover
  • Waterproof, solid state power module
  • 150amp capacity with 17 outputs
    • 4 rated @ 35A and 1 rated @ 30A
      (High In-Rush circuits)
    • 11 rated @ 15A, which can be combined for larger loads
    • 1 Low Side driver switch, rated @ 2A
  • Built-in Bluetooth module
  • Program and operate accessories with phone or tablet
  • System can be used to start vehicle

Switch Panel Specs:

  • RCR-Touch™ cover, snaps on for ease of specific switch selection while wearing gloves or riding rough terrain
  • Switch Panel enclosure measures
    4” L x 3” W x .375” H
  • Splash proof with Polycarbonate overlay faceplate
  • Pre-machined for factory- look installation
  • RGB backlighting
  • Orange LED switch indicators
  • 6 Programmable LED Status indicators

Power Module Specs:

  • 17 Outputs: 4 rated @ 35A, 1 rated @ 30A, 11 rated @15A, 1 Low Side rated @ 2A
  • 150A maximum rating
  • 7”L x 3.5”W x .5”H (excluding connectors)
  • Waterproof and Solid State
  • Under hood rated 125° to -40°C
  • LED Ignition Input Status Indicator

Kit Also Includes:

  • 11’ of Communication Cable between Switch Panel and Power Module
  • Power Cable with 150A inline Circuit protection
  • 100 User Selectable Legends included (Horizontal orientation)
  • Installation brackets and hardware
  • Color Coded Output wires
  • Wire harness with waterproof, sealed automotive grade connectors

Switches can be programmed to be: On/Off or Momentary, ignition or battery powered, flash, strobe, low voltage disconnect, and memorize previous settings.  There is also a programming function to adjust the brightness of backlighting and indicator LEDs.
